affordable led video wall for Supermarket window display
Product description
1. Advanced Inner and outer curve lock systems,Two side locks, with
angles of -7.5 ° , -5°, -2.5°, 0°,+2.5°, +5°, 7.5°, +10 ° screen.
2. Auto-locking vertical lock system for fast and easy 1 man
installation with ultimate safty and pixel protection.
3. Super lightweight and twice the size, perfect for the
operational demands of extra large outdoor display applications.
4. Shipping | Save weight, save cost Super lightweight 6 in 1
flight case, half weight of ordinary design.
5. Quick installation & Easy maintenance,Modular design for easy
disassembly, support front maintenance.
| Pixel Pitch | 2 mm |
| LED Lamp | SMD1515 |
| IC | ICN2153s |
| Module Size | 320x160mm |
| Module pixels | 160x80dots |
| Cabinet Size(WxHxD)(mm) | 960x480mm |
| Module Quantity(pcs) | 9 |
| Cabinet resolution WxH | 480x240dots |
| Cabinet Material | Iron |
| Cabinet Weight (kg) | 13 |
| Average Power/sqm (watts) | 174 |
| Max Power/sqm(watts) | 580 |
| Brightness | 800cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 2-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/40 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
Sole Agent
MPLED cooperated with local team to expand Led display business,
and signed sole agent in Saudi Arabia, Egypt, New Zealand, Germany
and Indonesia.
Also had local installation and maintenance team in Cambodia,
France, Middle East, Indonesia, United States, South Korea, Ghana.
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3.7/24 online remote control service , and local engineer service
within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years
experience.
7.Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
FAQ
1. Payment Terms?
We accept payment by bank transfer (T/T) , Credit Card on Alibaba,
or other payment terms you want that can contact us, payment should
be paid before delivery .
2. Shipment Way?
You can choose to use sea shipment or air freight or express by DHL
or such as this(UPS,FEDEX,TNT,EMS, ARAMEX).We can help you to book
ship or arrange the shipment, or you can use your own shipping
agent.
3.Warranty?
We offer a 3 year warranty service according different order, and
to provide technical guidance.We have a professional service team;
They are always online waiting to serve you.
During the warranty period, most of damaged parts could be replaced
free of charge.
4.Packaging ways for our led screen?
We provide Flight case or wooden case for led display board.
Customers can freely choose from them. But in any case, we will
both ensure the use of appropriate packaging to protect led display
board safety.
5. Delivery time?
It will depond on your project size
