Quick Installation Front Service Outdoor Concert Stage Background
Led Display
Product presentation
1. The industry's first maintenance module tool, more convenient
maintenance.
2. Select lamp beads to create flagship industry benchmarking
rental products.
3. Reduce brightness does not reduce gray, indoor and outdoor
general rental.
4. The second generation of anti-collision technology, effectively
prevent the lamp and faster maintenance.
5. Die-cast rear cover, higher strength, better heat dissipation,
stronger waterproof.
6. Ergonomic design handle, feel better, easy to lift and put
| Pixel Pitch | 3.91mm |
| LED Lamp | SMD1921 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 64x64dots |
| Cabinet Size(WxHxD)(mm) | 500x1000x88 mm |
| Module Quantity(pcs) | 8 |
| Cabinet resolution WxH | 128x256dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 14 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 4500-5000cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 3.91-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/16 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q1: Is the product customizable?
A: Yes,we can customize the product according to customers' needs,
you just need to provide the requirements details.
Q2: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q3:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q4: How about your warranty?
A: Different product offer different time frame warranty, but all
product here we offer 2year at least warranty.
Q5: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken
by us to assure that the goods are in a good condition during
storage and delivery.
Q6: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election
of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
