960x960mm HD P6 Outdoor LED Displays Full Color 6mm Pixel Pitch
Aie casting aluminum 960x960mm hd P6 led board display
Product presentation
1. The cabinet body is processed by CNC, with only ±0.1mm
tolerance, and 3 times precision that of the iron/steel cabinet
body.
2. Modules, power supplies and control cards can also be
disassembled directly from the front without leaving a maintenance
channel.
3. 3 seconds lock type installation to complete a module, save the
cost of manual installation, improve work efficiency, easy
maintenance.
4. The refresh rate of the whole screen can reach more than 3840Hz,
the gray level can be adjusted arbitrarily within 65536, and the
video can be played,High definition, can achieve the column and
column elimination, no stripes, no caterpillar and other
phenomena.The brightness reaches above 5500nit.
5. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc.
Yes, you can control in your convenient management. Many screens
together? No problem, your laptop can manage all of them whenever
and wherever.
6. Designed for working in all weather outdoor environments. High
protection grade of IP65 suitable for winter and cold areas like
North European countries and Russia, and high temperature like KSA,
Oman, UAE, etc.
7. The unique triple brim design can effectively block direct light
while protecting the screen, and at the same time prevent the
reflection of strong light on the LED screen. This design further
enhances the contrast on the conventional basis, giving the picture
quality a sense of hierarchy.
8. From the overall layout of PCB design, the product strictly
follows the design standards of EMC testing, and has the
performance that can withstand higher standards of electromagnetic
compatibility testing. Every detail is to improve the overall
stability of the display device.
| Pixel Pitch | 6.6mm |
| LED Lamp | SMD3535 |
| LED configuration | SMD 3 in 1 |
| Module Size | 320mm x 160mm |
| Module pixels | 48x24dots |
| Cabinet Size(WxHxD)(mm) | 960x960x108mm |
| Module Quantity(pcs) | 18 |
| Pixel Density | 144x144dots |
| Cabinet pixels | 20736 dots |
| Cabinet Weight (kg) | 28 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 600 |
| Brightness Control | 256 level |
| Gray scale | 14 bit |
| Refresh frequency | 1920hertz |
| Driving mode | 1/6 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1. 3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2. Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3. 7/24 online remote control service , and local engineer service
within 8 hours contact.
4. Free technical training in factory.
5. MPLED engineers will fly to the site if you need local service.
6. Expanding market plan with professional MPLED team over 8 years
experience.
7. Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
FAQ
1. Is the product customizable?
Yes, we can customize the product according to customers' needs,
you just need to provide the requirements details.
2. Do you test all your goods before delivery?
Yes, we have 100% test before delivery.
3. How about your delivery time? Generally, it will takes about
10-15 days after receiving your advance payment. The specific
delivery time depends on the items and the quantity of your order.
4. What is your terms of payment? T/T 30% as deposit, and 70%
before delivery. We'll show you the photos of the products and
packages before you pay the balance.
5. What is your terms delivery?
EXW, FOB, CFR, CIF, DDP, DDU...
