Full Color Rental LED Displays SMD1921 Church Public Backdrops
Full Color Led Video Wall Panel Indoor P3.91 P4.81 Hd Led Display
Church Public Backdrops
Product presentation
1. Modular Maintenance Faster and easier on-site maintenance
Magnetic tool for module front service; free of tool for module
rear service in 15s ,Easy modularized maintenance for power box in
10s.
2. Installation Protection ,Automatic edge protection & effective
corner protection,Protect the LEDs near the edge of the cabinet,
effectively reducing damage by 50% caused during
installation,Ensure that the LEDs are free from contact with the
ground when the cabinet is placed on the ground.
3. For small-sized exhibitions,A smart phone connects the sending
card or the video processor directly without needing a
computer.Manage, edit, and send the program through an APP on the
smart phone.Display a picture of any size within the resolution of
3,840*2,160.
4. Precise Arc, Fast Lock,9s to replace angle block, arcing
faster,From -5 °(convex) to +10°(concave), wide range of
curving,creative screen shapes and sizes
5. Aluminum die casting The die-cast magnesium cabinet weights only
7.5kg, 30% lighter than average.
6. HDR Technology ,High resolution, 16bit high gray level, Support
10bit video.
7. Automatic Calibration ,Calibration data will be updated
automatically when the module is replaced.
| Pixel Pitch | 4.81mm |
| LED Lamp | SMD1921 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 52x52dots |
| Cabinet Size(WxHxD)(mm) | 500x500x88 mm |
| Module Quantity(pcs) | 4 |
| Cabinet resolution WxH | 104x104dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 7.5 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 4500-5000cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 4.81-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/13 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
SHENZHEN MP LED TECHNOLOGY CO., LTD
1. Mature customized solution team with engineers support.
2. Serious material and procedure QC such as 72 hours working test,
shock proof test, waterproof test, material checkout, damp proof
package, etc.
3. Product updates each quarter to do improvement and innovations
to help our clients win more projects in their market.
4. Make our products more and more standard to save cost for
clients, such as same cabinet for many different pixel pitch led
modules, and P3.91, P4.81 of stage led module can also use for
indoor fixed installation WT/WD series.
