4500cd 3840Hz Outdoor Stage Rental LED Screen Nationstar Gold
Thread
4500cd 3840Hz Nationstar Gold Thread Outdoor Led Screen For Rent
Product presentation
1. The PCB board thickness of is 1.6mm.Compared with the ordinary
PCB board, the circuit layout is more reasonable, with better heat
dissipation effect, and more stable working condition.
2. Calibrate data automatically, No need to re-calibratedata on the
new modules while doing the replacement.Just plug and play.
3. Low brightness and Hight gray scale:14Bit-16Bit gray scale to
bring perfect display performance with no shadows.
4. Advanced Inner and outer curve lock systems,Two side locks, with
angles of -7.5 ° , -5°, -2.5°, 0°,+2.5°, +5°, 7.5°, +10 °
screen.Flat, concave and convex screens can be realized by using
connection accessories.
5. Flip-Shield— Comprehensive Corner Protection,Effectively avoid
accidental impact from the lamp face, top and side, so as to
achieve the effect of three-dimensional(3D) surface protection.
6. Transportation Protection,High strength flight case,12mm thick
birch wood layer, high-strength casters,Shockproof, anti-collision,
the sturdiest protection. concert led screen
| Pixel Pitch | 3.91mm |
| LED Lamp | SMD2121 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 64x64dots |
| Cabinet Size(WxHxD)(mm) | 500x500x88 mm |
| Module Quantity(pcs) | 4 |
| Cabinet resolution WxH | 128x128dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 7.5 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 4500-5000cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 3.91-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/16 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3.7/24 online remote control service , and local engineer service
within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years
experience.
7.Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
Sole Agent
MPLED cooperated with local team to expand Led display business,
and signed sole agent in Saudi Arabia, Egypt, New Zealand, Germany
and Indonesia.
Also had local installation and maintenance team in Cambodia,
France, Middle East, Indonesia, United States, South Korea, Ghana.
FAQ
Q1:What’s the function?
A1:Support various formats,like VGA,Video,AVI,DAT,etc.
Q2:LED display modules are generally expressed in PX,such as P2 P3
P4...P8 P10,what does this mean?
A2:P3 P4...P8 P10 means that the pixel pitch is 3mm
4mm...10mm,which determines resolution of a display.Pixel pitch
smaller,led resolution higher.
Q3:What pixel pitch should I choose on my display?
A3:It’s mainly depends on the viewing distance,the size of the
display screen,the desired effect the application scenario and the
customer budget.
Q4:How to in stall?
A4:Free of charge to provide detailed steel structure drawings and
installation guidance and wiring diagram,free remote debugging.We
can also send our engineers to the site to guide the installation
if needed.
Q5:What about your quality?
A5:The quality of our display is excellent.We use the materials of
high quality suppliers.strictly control the production process,and
pass the multiple quality inspection to ensure that every product
is qualified.
Q6:How about the warranty?
A6:Two years warranty
Q7:What kind of display we provide?
A7:We have indoor/outdoor/rental/Advertising/transparent and poster
LED display for your choice.
Q8: Is the product customizable?
A: Yes,we can customize the product according to customers' needs,
you just need to provide the requirements details.
Q9: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q10:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q11: How about your warranty?
A: Different product offer different time frame warranty, but all
product here we offer 2year at least warranty.
Q12: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken
by us to assure that the goods are in a good condition during
storage and delivery.
