Quick Installation Indoor LED Displays 128x64 Dots Low Power
Consumption
Quick Installation Kinglight Church Led Display Low Power
Consumption
Product description
1. The wide viewing angle (H160° / V160° )covers a larger viewable
space and enables more viewers to experience the stunning details.
2. The world's first golden ratio of 16:9 standard cabinet,
Consistent with the pupil ratio of the human eye,Compatible with
2K, 4K and 8K ,Bezel-free.
3. Through the smooth optical design technology, filter the stray
light effect and make the chips have even light. Achieve a large
perspective, no sense of particles when watching and it is
comfortable and healthy to watch close for a long time.
4. Supports the front maintenance of the module, power supply, and
receiving card, no need to set up a special maintenance channel,
and save installation space.
5. The module has its own calibration data storage function to
ensure that the uniformity of the screen brightness and
chromaticity will not be affected after the module is replaced.
6. Featuring dual receiving cards & dual power supply, the product
ensures continuity of information transmission with no power cut or
signal loss, particularly for control room and studio scenarios.
| Pixel Pitch | 2.5 mm |
| LED Lamp | SMD2121 |
| IC | ICN2153s |
| Module Size | 320x160mm |
| Module pixels | 128x64 dots |
| Cabinet Size(WxHxD)(mm) | 960x480mm |
| Module Quantity(pcs) | 9 |
| Cabinet resolution WxH | 384x192dots |
| Cabinet Material | Iron |
| Cabinet Weight (kg) | 13 |
| Average Power/sqm (watts) | 174 |
| Max Power/sqm(watts) | 580 |
| Brightness | 1200cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 2.5-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/32 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP31 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1. 3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2. Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3. 7/24 online remote control service , and local engineer service
within 8 hours contact.
4. Free technical training in factory.
5. MPLED engineers will fly to the site if you need local service.
6. Expanding market plan with professional MPLED team over 8 years
experience.
7. Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
Projects
2017, MPLED P6 outdoor led display assist for Senator Election of
South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
Senior Engineers
Over 17 years experience electronic engineer to support our
customized solutions for indoor and outdoor led display project.
Over 12 years experience structural engineer to support our
structure drawings .
10 years experience pre-sale and after-sale engineer for online
service and technology training.
FAQ
Q1: Is the product customizable?
A: Yes,we can customize the product according to customers' needs,
you just need to provide the requirements details.
Q2: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q3: What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q4: How about your warranty?
A: Different product offer different time frame warranty, but all
product here we offer 2year at least warranty.
Q5: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken
by us to assure that the goods are in a good condition during
storage and delivery
