P2.5 Indoor Led Advertising Screens 8K 1200cd High Brightness
High Brightness Wall Mounted P2 5 LED Screen Curve Front Service
Product description
1. Perfect 16:9 display ratio and can be spliced into standard
resolution of 2K/4K/8K.
2. Used for residential, commercial, and light industry, etc., with
safety guarantee. Complies with EMC Class B standards.
3. The product uses frameless design. With the help of professional
sewing software, the spliced screen becomes a complete large
display scree.
4. The module has its own calibration data storage function to
ensure that the uniformity of the screen brightness and
chromaticity will not be affected after the module is replaced.
5. Support three installation methods: hoisting, wall-mounted, and
floor-mounted installation.
6. Used in high-tech companies, enterprises and institutions,
hotels, transportation hubs, commercial real estate and other
industries.
| Pixel Pitch | 2.5 mm |
| LED Lamp | SMD2121 |
| IC | ICN2153s |
| Module Size | 320x160mm |
| Module pixels | 128x64dots |
| Cabinet Size(WxHxD)(mm) | 960x960mm |
| Module Quantity(pcs) | 9 |
| Cabinet resolution WxH | 384x192dots |
| Cabinet Material | Iron |
| Cabinet Weight (kg) | 13 |
| Average Power/sqm (watts) | 174 |
| Max Power/sqm(watts) | 580 |
| Brightness | 1200cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 2.5-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/32 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1. 3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2. Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3. 7/24 online remote control service , and local engineer service
within 8 hours contact.
4. Free technical training in factory.
5. MPLED engineers will fly to the site if you need local service.
6. Expanding market plan with professional MPLED team over 8 years
experience.
7. Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
FAQ
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor 2.5 MM
Q2: Where is it used for?
A2: Indoor rental use. Widely used for backdrop of staging event,
rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling
system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar.
Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We
will offer the suitable solution for your project size. I will
appreciate it if any drawing files about installation offered.
LED display,also called led screen, led video wall, or led sign,
with its unique advantages,has gradually replaced the traditional
billboards, light boxes,projectors etc. LED display has become a
new force in the media industry.
