Double Pillar Type P10 Outdoor LED Displays IP65 Billboard Led
Screen
Double Pillar Type Outdoor Fixed High Brightness P10 Business Led
Signs
Product presentation
1. The cabinet body is processed by CNC, with only ±0.1mm
tolerance, and 3 times precision that of the iron/steel cabinet
body.
2. Super strong anti-UV, anti-level 12 storm, anti-severe cold,
corrosion resistance, adapt to various harsh environments.
3. Cluster control, remote publishing, synchronous display.
4. Savings in Electricity Costs,300 Sqm, 5 years , Save $200,000 on
Electricity Costs.
5. Fanless design prevents dust and water vapor from being brought
into the cabinet.
6. The 304 stainless steel screws and locks, the aluminum panel,
and the double protection of strongly-insulated wires wrapped in
fiberglass, thereby ensuring longer service life of our products.
7. High Brightness,High Gray Scale,High Contrast Ratio,High Refresh
Rate,Wide color gamut,High level driving IC.
| Pixel Pitch | 10mm |
| LED Lamp | SMD3535 |
| LED configuration | SMD 3 in 1 |
| Module Size | 320mm x 160mm |
| Module pixels | 32x16dots |
| Cabinet Size(WxHxD)(mm) | 960x960x108mm |
| Module Quantity(pcs) | 18 |
| Cabinet resolution WxH | 96x96dots |
| Cabinet Material | magnesium alloy |
| Cabinet Weight (kg) | 29 |
| Average Power/sqm (watts) | 240 |
| Max Power/sqm(watts) | 800 |
| Brightness | 6500cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 10-200 meters |
| Brightness Control | 256 level |
| Gray scale | 14 bit |
| Refresh frequency | 1920hertz |
| Driving mode | 1/2 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | Input Voltage |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences,
Governments,Banks,Churches, Highways,Airports,Parliaments,Education
institutes,Hotel,Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election
of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
