Curved Indoor Outdoor Stage Rental LED Displays Smd Full Color
250x250mm
Stage Rental Arc Led Display Curved Indoor Outdoor Smd Full Color
Rental Led Display
Product presentation
1.High end aluminum base stacking, Wall mounting , Structure for wall
mounting, Steel base stacking.
2. Cabinet is very thin which makes it ultra-lightweight and space
saving. It Can be installed at any area without requiring much
space. The light weight of 7.5kg/panel LED screen is easy to carry,
transport and install, saving good amount of money on your labor
costs.
3. Each module within a panel stores calibration and operating
parameters separately.
4. Adding quicker and easier camera set up and handling. Its
on-camera performance is unrivaled, ideal for film applications.
5. Has four corner protectors in each corner to prevent LED to be
damaged,more security for transport, installation, operation,
assemble & disassemble foldable design, and easy to use.
6. High Precision Curve Lock design (-10° to +10°) is adopted to
solve the problem that the old curved lock is difficult to use
before. Rotational control, more accurate, easy to use and quickly
adjust curve degree.
7. For small-sized exhibitions,A smart phone connects the sending
card or the video processor directly without needing a
computer.Manage, edit, and send the program through an APP on the
smart phone.Display a picture of any size within the resolution of
3,840*2,160.
| Pixel Pitch | 2.6mm |
| LED Lamp | SMD2121 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 96x96dots |
| Cabinet Size(WxHxD)(mm) | 500x500x88 mm |
| Module Quantity(pcs) | 4 |
| Cabinet resolution WxH | 192x192 dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 4 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 800-1000cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 2.6-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 1920hertz |
| Driving mode | 1/32 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
SHENZHEN MP LED TECHNOLOGY CO., LTD
1.18 years+ engineer team fully support your project.
2. 7/24 service,remote techinical support.
3. Qucik reply within 3 hours.
4. Solution completed within 6 hours.
5. All documents(structure drawings,power/signals connection
drawings and manuals) will be prepared before delivery.
