No Noise Conference Led Screen 1.8mm 172x86 Dots High Contrast
1.8mm High Contrast No Noise Large Screen For Conference Room
Product description
1. Full HD resolution, Automatic brightness adjustment system;
2. Support 8-channel mirroring access and 4-signal split display
simultaneously; Support Android, iOS, Windows & Mac OS system
mirroring with ˂160ms ultra-low latency; Support two-way WiFi
connection without signal interference between mirroring and
networking.
3. Smart Inkject Craftsmanship is optional to improve contrast
ratio greatly; Nano-Coating Protection Technology stabilizes
display effect optionally.
4. Optional sizes & colors meet customized needs; Support double
METAGO joint splicing and different installation like wall mounting
and moble standing; Applicable on various occasions like medium and
large meeting rooms, lecture theaters, exhibition halls and private
cinemas.
5.Supporting installlation and maintenance while live working
6.power on/off, brightness adjustment, signal source switching,
menu settings, and other functions can be easily realized.
| Pixel Pitch | 1.8mm |
| LED Lamp | SMD1515 |
| IC | ICN2153 |
| Module Size | 320x160mm |
| Module pixels | 172x86 dots |
| Cabinet Size(WxH)(mm) | 680x480mm |
| Module Quantity(pcs) | 6 |
| Cabinet resolution WxH | 344x256dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 7 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 600 |
| Brightness | 800cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 1.8-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/43 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
Projects
2017, MPLED P6 outdoor led display assist for Senator Election of
South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3.7/24 online remote control service , and local engineer service
within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years
experience.
7.Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
Sole Agent
MPLED cooperated with local team to expand Led display business,
and signed sole agent in Saudi Arabia, Egypt, New Zealand, Germany
and Indonesia.
Also had local installation and maintenance team in Cambodia,
France, Middle East, Indonesia, United States, South Korea, Ghana.
FAQ
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor 2.6 MM
Q2: Where is it used for?
A2: Indoor rental use. Widely used for backdrop of staging event,
rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling
system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar.
Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We
will offer the suitable solution for your project size. I will
appreciate it if any drawing files about installation offered.
LED display,also called led screen, led video wall, or led sign,
with its unique advantages,has gradually replaced the traditional
billboards, light boxes,projectors etc. LED display has become a
new force in the media industry.
