160x80 Dots High Brightness Led Display P2 Indoor Digital Sign
High Brightness Wall Mounted Type Curve P2 Indoor Digital Sign
High Brightness Led Display Product description
1. Modules magnetic front installation, 3 seconds front
maintenance.
2. Wall-mounting installation, ground-standing installation and
90°corner/rotation installation available.
3. More reliable and more suitable for the important projection
like security monitoring, exhibition hall display and the
enterprise meeting.
4. Cabinet, excellent heat dissipation effectively improve the
reliability of electronic components.
5. Wireless design on the back for fire and rodent prevention.
6. Cabinet size, cabinet size can be customized according to
project demands.
| Pixel Pitch | 2 mm |
| LED Lamp | SMD1515 |
| IC | ICN2153s |
| Module Size | 320x160mm |
| Module pixels | 160x80 dots |
| Cabinet Size(WxHxD)(mm) | 960x960mm |
| Module Quantity(pcs) | 18 |
| Cabinet resolution WxH | 480x480dots |
| Cabinet Material | Iron |
| Cabinet Weight (kg) | 27 |
| Average Power/sqm (watts) | 160 |
| Max Power/sqm(watts) | 530 |
| Brightness | 800cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 2-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/40 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project
execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections
of led display which guide for site cable arrangement and structure
preparation in advance.
3.7/24 online remote control service , and local engineer service
within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years
experience.
7.Multiple options for global transportation, like FOB, CIF, DDP,
DDU to most countries.
Sole Agent
MPLED cooperated with local team to expand Led display business,
and signed sole agent in Saudi Arabia, Egypt, New Zealand, Germany
and Indonesia.
Also had local installation and maintenance team in Cambodia,
France, Middle East, Indonesia, United States, South Korea, Ghana.
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences,
Governments,Banks,Churches, Highways,Airports,Parliaments,Education
institutes,Hotel,Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election
of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
