HDR Indoor Small Pitch LED Display Board IP31 320x160mm Windows XP
System
Command P1.875 Ultra Wall-Mounted HD Indoor Seamless Led Video Wall
Product description
1. custom HDR image algorithm technology, to render optimum peak
brightness and contrast for every frame image, to display
true-to-life imagery.
2. Perfect 16:9 display ratio and can be spliced into standard
resolution of 2K/4K/8K.
3. The product uses frameless design. With the help of professional
sewing software, the spliced screen becomes a complete large
display screen.
4. ALL-IN-ONE solution guarantees stunning visual performance and
stable operation with zero noise. Integrated with multiple
interactive functions like touch-screen writing, electronic
whiteboard, wireless projection, and remote conference, etc., it
fully bridges the gap between multimedia demonstration and
knowledge collaboration.
5. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc.
Yes, you can control in your convenient management. Many screens
together? No problem, your laptop can manage all of them whenever
and wherever.
| Pixel Pitch | 1.8mm |
| LED Lamp | SMD1515 |
| IC | ICN2153 |
| Module Size | 320x160mm |
| Module pixels | 172x86dots |
| Cabinet Size(WxH)(mm) | 680x480mm |
| Module Quantity(pcs) | 6 |
| Cabinet resolution WxH | 344x256dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 7 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 600 |
| Brightness | 800cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 1.8-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/43 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
Projects
2017, MPLED P6 outdoor led display assist for Senator Election of
South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in
Russia
2019, MPLED P2.97 stage led display stand the stage for Senator
Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in
Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in
Kuwait landmark
FAQ
Q1: Is the product customizable?
A: Yes,we can customize the product according to customers' needs,
you just need to provide the requirements details.
Q2: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q3:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q4: How about your warranty?
A: Different product offer different time frame warranty, but all
product here we offer 2year at least warranty.
Q5: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken
by us to assure that the goods are in a good condition during
storage and delivery.
