Double Pillar Outdoor LED Advertising Screen Hd Full Color 1920
Hertz
Double Pillar Type Hd Full Color Front Service P8 Outdoor Led
Screen
Product description
1. Designed for working in all weather outdoor environments. High
protection grade of IP65 suitable for winter and cold areas like
North European countries and Russia, and high temperature like KSA,
Oman, UAE, etc.
2. Thin Panel,Convenient Transport,Save Transport Cost, save steel
structure.
3. High resolution and clarity
4. The cabinet can be compatible with a variety of module models,P2.5
P3 P4 P5 P6 P8 P10(320x160mm) can be replaced directly..
5. The 304 stainless steel screws and locks, the aluminum panel, and
the double protection of strongly-insulated wires wrapped in
fiberglass, thereby ensuring longer service life of our products.
6. Stage,Sports,advertising,traffic,events,stadium,shopping
center,airport,exhibitions, car shows, fashion shows, concerts,
ceremonies, entertainment,etc.
7. With 140°-160 ° ultra-wide viewing angle, the screen can be seen
from various positions.
| Pixel Pitch | 8mm |
| LED Lamp | SMD3535 |
| LED configuration | SMD 3 in 1 |
| Module Size | 320mm x 160mm |
| Module pixels | 40x20dots |
| Cabinet Size(WxHxD)(mm) | 960x960x108mm |
| Module Quantity(pcs) | 18 |
| Cabinet resolution WxH | 120x120dots |
| Cabinet Material | magnesium alloy |
| Cabinet Weight (kg) | 29 |
| Average Power/sqm (watts) | 240 |
| Max Power/sqm(watts) | 800 |
| Brightness | 6500cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 8-200 meters |
| Brightness Control | 256 level |
| Gray scale | 14 bit |
| Refresh frequency | 1920 hertz |
| Driving mode | 1/5 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q1:What is the control system? How is it?
A:We use Nova Taurus Series asynchronous control system. Support
cluster play and managementSupportAPP/PhoneWIFIIpad/Laptop/PC/Cloud
control. It's very easy and convenient to control.
Q2:What is your best service?
A:One to one sales engineer to customer responsibility system. We
will do:
1. Know your proiect and provide the best solution for it
2. Track your order and let you know each step and detail of it:
3. Teachyou how to install and use the screen;
4. Care the subsequent use of your screen and ensure vour after
-sales service be well
5...6...etc.
Q1:How about your delivery time?
A:Generally. it will take 15 to 25 days after receiving your
advance payment. The spe- cific delivery time depends on the items
and the quantity of your order.
Q3:How about your Warranty Term?
A:2-5year warranty. Structure design,installation problem,program
the screen. how to use the screen... don't worry,we have
professional after-sale team to solve your any questions after you
placed an order. And your exclu-sive sales engineer will also help
you get over any problems.
